Sensenich Wooden Propellers
Sensenich Wood Propeller Company began business in 1932
|
This page contains the common Sensenich number designations. A number of propellers were built in the early forties under military contract using the year of contract as the first digits of the design number. See "Military Contract Drawing Numbers" if your propeller has some variation of "42K12335", "43K15131", etc., etc.
Sensenich props are stamped with a number known as a drawing or design number. The logic of the drawing number sequence is the first number is the length in inches, the middle letters designate the engine and the final digits are the pitch. For example, a 72CK-44 is a 72 inch prop for a Continental engine and has a pitch of 44 inches. There are a few exceptions to this logic.
The table below is arranged in drawing number order. Locate the drawing number in the left column then read across to locate the aircraft and engine combination the prop was designed to be used on. This is a fairly large page; it may be easier to locate your prop by using the search or find tools of your web browser.
Sensenich serial numbers/Date of manufacture. To my knowledge Sensenich is the only manufacturer for which we have been able to correlate serial numbers with approximate date of manufacture.
Drawing No.
|
Aircraft
|
Engine
|
60MY-49
|
Mooney M-18L/LA
|
Lycoming O 145 B/65
|
63-A
|
Aeronca C2
|
Aeronca E 107 A
|
65CK-58
|
Mooney M-18C/C 55
|
Continental A-65/65
|
65CK-60
|
Mooney M-18C/C 55
|
Continental A-65/65
|
65CK-62
|
Mooney M-18C/C 55
|
Continental A-65/65
|
66CB-52
|
Mooney M-18L/LA
|
Lycoming O 145 B/65
|
69A-28
|
Aeronca C3
|
Aeronca E 113, A, B, C/36
|
Welch OW6M
|
Aeronca E 113, A, B, C/36
|
|
69A-30
|
Aeronca K C
|
Aeronca E 113 CB, CDB
|
69C-23
|
Piper E 2
|
Continental A 40/40
|
Piper J 2, J 3, C40
|
Continental A 40/40
|
|
69C-26
|
Piper E 2
|
Continental A 40/40
|
Piper J 2, J 3, C40
|
Continental A 40/40
|
|
69J-28
|
Aeronca K C
|
Continental A 40/40
|
Porterfield CP40, CP40A
|
Continental A 40/40
|
|
Taylorcraft A
|
Continental A 40/40
|
|
Welch OW5M
|
Continental A 40/40
|
|
707-80
|
Cessna T50, AT17
|
Jacobs L 4 MB/225-245
|
Cessna UC-78
|
Jacobs L 4 MB/225
|
|
70A-52
|
Culver LCA
|
Continental A 75/75
|
70A-54
|
Culver LCA
|
Continental A 75/75
|
70AB-56
|
Culver Cadet LFA
|
Franklin 67KW 90hp
|
70AF-52
|
Culver LFA
|
Franklin 4 AC 176 D 3/80
|
70AF-54
|
Culver LFA
|
Franklin 4 AC 176 F 3/80
|
70D-40
|
Piper J4E, F, J5A
|
Continental A75/75
|
Stinson HW75
|
Continental A75/75
|
|
70D-42
|
Piper J4E, F, J5A
|
Continental A75/75
|
Rearwin Skyranger 180
|
Continental A 80/80
|
|
Stinson HW75
|
Continental A75/75
|
|
Stinson 10, 10S, HW75
|
Continental A 80/80
|
|
70D-44
|
Piper J4E, F
|
Continental A75/75
|
Porterfield 75C
|
Continental A75/75
|
|
Rearwin Skyranger 175
|
Continental A75/75
|
|
70DF-48
|
Rearwin 180 F
|
Franklin 4 AC 176 F 3/80
|
70DK-40
|
Piper J 3 C 75 Duster
|
Continental A 75/75
|
Piper J 4 E
|
Continental A 75/75
|
|
Piper J 5 A
|
Continental A 75/75
|
|
Stinson 10, H W 75
|
Continental A 75/75
|
|
Stinson 10, 105, H W 75
|
Continental A 80/80
|
|
70DK-42
|
Piper J 4 E
|
Continental A 75/75
|
Piper J 5 A
|
Continental A 75/75
|
|
Piper L 4E, F
|
Continental A 75/75
|
|
Rearwin Skyranger 175
|
Continental A 75/75
|
|
Stinson 10, H W 75
|
Continental A 75/75
|
|
Stinson 10, 105, H W 75
|
Continental A 80/80
|
|
70DK-44
|
Piper J 4 E
|
Continental A 75/75
|
Piper L 4E, F
|
Continental A 75/75
|
|
Rearwin 175
|
Continental A 75/75
|
|
70F-43
|
Piper J 3 F 50
|
Franklin 4 AC 150/50
|
Taylorcraft BF
|
Franklin 4 AC 150/50
|
|
70F-45
|
Aeronca 50F
|
Franklin 4AC 150/50
|
Aeronca 60TF
|
Franklin 4AC 150/60
|
|
Piper J 3 F 50, F 60 S
|
Franklin 4 AC 150/50
|
|
Taylorcraft BF
|
Franklin 4 AC 150/50
|
|
Taylorcraft L2G, L
|
Franklin 4 AC 150/50
|
|
70F-47
|
Aeronca 50F
|
Franklin 4AC 150/50
|
Aeronca 60TF
|
Franklin 4AC 150/60
|
|
Piper J 3 F 60
|
Franklin 4 AC 171, 4 AC 150
|
|
Piper J 4 B
|
Franklin 4 AC 171/60
|
|
Taylorcraft BF60
|
Franklin 4 AC 171/60
|
|
70L-43
|
Piper J 3 L, J3LS
|
Lycoming O 145 A 1/50
|
Taylorcraft BLS
|
Lycoming O 145 A 1/50
|
|
70L-45
|
Aeronca 50L, 50AL, 50TL (55 HP)
|
Lycoming O 145 A 2/55
|
Aeronca 50L, 50AL, 50TL (50 HP)
|
Lycoming O 145 A 1/50
|
|
Piper J 3 L (50 HP)
|
Lycoming O 145 A 1/50
|
|
Piper J 3 L (55 HP)
|
Lycoming O 145 A 2/55
|
|
Taylorcraft L
|
Lycoming O 145 A 1/50
|
|
70L-47
|
Aeronca 50L, 50AL, 50TL (55 HP)
|
Lycoming O 145 A 2/55
|
Aeronca 50L, 50AL, 50TL (50 HP)
|
Lycoming O 145 A 1/50
|
|
Piper J 3 L (55 HP)
|
Lycoming O 145 A 2/55
|
|
Taylorcraft L
|
Lycoming O 145 A 2/55
|
|
70LY-32
|
Piper J 3 L 65 S
|
Lycoming O 145 B/65
|
70LY-34
|
Aeronca L3G, H
|
Lycoming O 145 B 2/65
|
Aeronca 65 TL, 65 TAL, 65 LA, 65 LB
|
Lycoming O 145 B 2/65
|
|
Piper J 3 L 65, J 3 L 65 S
|
Lycoming O 145 B/65
|
|
Piper J 4 F
|
Lycoming O 145 B/65
|
|
Piper L 4C
|
Lycoming O 145 B2/65
|
|
70LY-36
|
Aeronca L3G, H
|
Lycoming O 145 B 2/65
|
Aeronca 65TL, 65TAL, 65LA, 65LB
|
Lycoming O 145 B 2/65
|
|
Piper J 3 L 65, J 3 L 65 S
|
Lycoming O 145 B/65
|
|
Piper J 4 F
|
Lycoming O 145 B/65
|
|
Piper PA-15
|
Lycoming O 145 B/65
|
|
Porterfield LP 65
|
Lycoming O 145 B/65
|
|
Taylorcraft BF-65, BF-1265, DL-65
|
Lycoming O 145 B/65
|
|
Taylorcraft BL, BL1265, Tandem
|
Lycoming O 145 B/65
|
|
Taylorcraft L2D, F, J
|
Lycoming O 145 B 2/65
|
|
70LY-38
|
Luscombe 8B
|
Lycoming O 145 B/65
|
Piper PA-15, J4F
|
Lycoming O 145 B/65
|
|
Porterfield LP 65
|
Lycoming O 145 B/65
|
|
Taylorcraft BF-65, BF-1265, DL-65
|
Lycoming O 145 B/65
|
|
Taylorcraft L2D, F, J
|
Lycoming O 145 B 2/65
|
|
Taylorcraft BL, BL1265, Tandem
|
Lycoming O 145 B/65
|
|
70LY-40
|
Luscombe 8B
|
Lycoming O 145 B/65
|
72A
|
Aeronca K S
|
Aeronca E 113
|
72A-30
|
Aeronca K S
|
Aeronca E 113, C, CB, CDB
|
72C-42
|
Aeronca 65 TC, 65 TAC, L 3, 058B
|
Contintental 65
|
Aeronca 65C, 65 CA, 7AC, 11 AC
|
Contintental 65
|
|
Piper J3C65, L4, NE1, J4A
|
Contintental 65
|
|
Taylorcraft BC 65, BC 12 65, L2, DCO65
|
Continental A 65/65
|
|
72C-44
|
Aeronca 65 TC, 65 TAC, L 3, 058B
|
Contintental 65
|
Aeronca 65C, 65 CA, 7AC, 11 AC
|
Contintental 65
|
|
Interstate SIA Cadet
|
Continental A 65/65
|
|
Piper J 4 A
|
Continental A 65/65
|
|
Porterfield CP65
|
Continental A 65/65
|
|
Rearwin Skyranger 165
|
Continental A 65/65
|
|
Taylorcraft BC 65, BC 12 65, L2, DCO65
|
Continental A 65/65
|
|
Taylorcraft BC 12D
|
Continental A 65/65
|
|
72C-44M
|
Ercoupe 415 C
|
Continental A 65
|
72CK-40
|
Piper J 3 C 65
|
Continental A 65/65
|
Piper J 3 C 65 Duster
|
Continental A 65/65
|
|
Piper PA-11, PA-17
|
Continental A 65/65
|
|
72CK-42
|
Aeronca L3A, B, C, E, F, J
|
Continental A 65/65
|
Aeronca 65TC, 65TAC, O58, 65C, 65CA
|
Continental A 65/65
|
|
Aeronca 7 AC, 11AC, 11ACS
|
Continental A 65/65
|
|
Ercoupe 415C
|
Continental A 65/65
|
|
Interstate S 1 A
|
Continental A 65/65
|
|
Piper J 3 C 65
|
Continental A 65/65
|
|
Piper J 4 A
|
Continental A 65/65
|
|
Piper L 4, A, B, H
|
Continental A 65/65
|
|
Piper PA-11, PA-17
|
Continental A 65/65
|
|
Porterfield C P 65
|
Continental A 65/65
|
|
Rearwin 165
|
Continental A 65/65
|
|
Rose Parrakeet A-2
|
Continental A 65/65
|
|
Taylorcraft BC-65, BC-12 65, L2
|
Continental A 65/65
|
|
Taylorcraft BC-12D, BC-12D1
|
Continental A 65/65
|
|
Taylorcraft DC-65, DCO-65
|
Continental A 65/65
|
|
Taylorcraft L2A, B, H, M
|
Continental A 65/65
|
|
72CK-44
|
Aeronca L3A, B, C, E, F, J
|
Continental A65/65
|
Aeronca 65TC, 65TAC, O58, 65C, 65CA
|
Continental A 65/65
|
|
Aeronca 7 AC, 11AC, 11ACS
|
Continental A 65/65
|
|
Ercoupe 415C
|
Continental A 65/65
|
|
Interstate S 1 A
|
Continental A 65/65
|
|
Piper J 3 C 65
|
Continental A 65/65
|
|
Piper J 4 A
|
Continental A 65/65
|
|
Piper PA-11, PA-17
|
Continental A 65/65
|
|
Porterfield C P 65
|
Continental A 65/65
|
|
Rearwin 165
|
Continental A 65/65
|
|
Rose Parrakeet A-2
|
Continental A 65/65
|
|
Taylorcraft BC-65, BC-12 65, L2
|
Continental A 65/65
|
|
Taylorcraft BC-12D, BC-12D1
|
Continental A 65/65
|
|
Taylorcraft DC-65, DCO-65
|
Continental A 65/65
|
|
Taylorcraft L2A, B, H, M
|
Continental A 65/65
|
|
72DF-48
|
Interstate S 1 A 90 F
|
Franklin 4AC 199 E 2 /90
|
Stinson 10 A
|
Franklin 4 AC 199 E2/90
|
|
Stinson L 9A, B
|
Franklin 4 AC 199 E 3/90
|
|
72DF-49
|
Stinson 10 A
|
Franklin 4 AC 199 E2/90
|
Stinson L 9A, B
|
Franklin 4 AC 199 E 3/90
|
|
Interstate S 1 A 90 F
|
Franklin 4AC 199 E 2 /90
|
|
Rearwin Skyranger 190F
|
Franklin 4AC 199 E 2 /90
|
|
72F-40
|
Piper J4B, J3F60
|
Franklin 4 AC 171/60
|
Taylorcraft BF60
|
Franklin 4 AC 171/60
|
|
72F-42
|
Aeronca L3D
|
Franklin 4 AC 176 B2/65
|
Aeronca 65TF, 65TAF
|
Franklin 4AC 176 B2/65
|
|
Interstate S 1 A 65 F
|
Franklin 4AC 176 B 2/65
|
|
Piper J 3 F 65
|
Franklin 4 AC 176 B/65
|
|
Piper L 4D
|
Franklin 4 AC 176 B 2/65
|
|
Taylorcraft BF-65, BF-1265, Tandem
|
Franklin 4 AC 176 B2/65
|
|
Taylorcraft DF-65
|
Franklin 4 AC 176/65
|
|
Taylorcraft L2E, K
|
Franklin 4 AC 176 B 2/65
|
|
72F-44
|
Aeronca L3D
|
Franklin 4 AC 176 B2/65
|
Aeronca 65TF, 65TAF
|
Franklin 4AC 176 B2/65
|
|
Interstate S 1 A 65 F
|
Franklin 4AC 176 B 2/65
|
|
Piper J 3 F 65
|
Franklin 4 AC 176 B/65
|
|
Porterfield F P 65
|
Franklin 4 AC 176 B 1/65
|
|
Taylorcraft BF-65, BF-1265, Tandem
|
Franklin 4 AC 176 B2/65
|
|
Taylorcraft DF-65
|
Franklin 4 AC 176/65
|
|
Taylorcraft L2E, K
|
Franklin 4 AC 176 B 2/65
|
|
72F-46
|
Porterfield F P 65
|
Franklin 4 AC 176 B 1/65
|
72F-47
|
Piper J 3 F 60
|
Franklin 4 AC 171, 4 AC 150
|
72GA-46
|
Luscombe 8C, 8D
|
Continental A 75/75
|
72GA-48
|
Luscombe 8C, 8D
|
Continental A 75/75
|
72GA-50
|
Luscombe 8E
|
Continental C 85/85
|
72GK-42
|
Piper J 3 Duster & Sprayer
|
Continental C 85/85
|
72GK-44
|
Aeronca 7DC, 11CC
|
Continental C 85/85
|
Piper J 3 Duster & Sprayer
|
Continental C 85/85
|
|
72GK-46
|
Aeronca 7DC, 11CC
|
Continental C 85/85
|
Luscombe 8C, 8D
|
Continental A 75/75
|
|
Taylorcraft 19
|
Continental C 85/85
|
|
72GK-48
|
Aeronca 7BCM, 11BC
|
Continental C 85/85
|
Champion 7E C
|
Continental C 90/90
|
|
Luscombe 8C, 8D
|
Continental A 75/75
|
|
Luscombe 8E
|
Continental C 85/85
|
|
Piper PA-11 Seaplane (90 HP)
|
Continental C 90/90
|
|
Taylorcraft BC12D85, BC12D485
|
Continental C 85/85
|
|
Taylorcraft 19
|
Continental C 85/85
|
|
Aeronca 7EC, 7CCM
|
Continental C 90/90
|
|
Funk B 85 C
|
Continental C 85/85
|
|
72GK-50
|
Aeronca 7BCM, 11BC
|
Continental C 85/85
|
Aeronca 7EC, 7CCM
|
Continental C 90/90
|
|
Champion 7E C
|
Continental C 90/90
|
|
Luscombe 8E
|
Continental C 85/85
|
|
Luscombe 8F
|
Continental C 90/90
|
|
Piper PA-11, PA-18
|
Continental C 90/90
|
|
Taylorcraft BC12D85, BC12D485
|
Continental C 85/85
|
|
72GK-52
|
Piper PA-11, PA-18
|
Continental C 90/90
|
72KZL-49
|
McCulloch J-2
|
Lycoming O 360/180
|
72KZL-52
|
McCulloch J-2
|
Lycoming O 360/180
|
72KZL-54
|
McCulloch J-2
|
Lycoming O 360/180
|
72L
|
Piper J3P
|
Lenape L M 3, AR3 160/50
|
73BG-54
|
Globe Swift GC 1 B (G HUB)
|
Continental C 125/125
|
73BR-44
|
Aeronca 15AC
|
Continental C 145/145
|
73BR-50
|
Cessna 170, 170A
|
Continental C 145/145
|
73BR-54
|
Globe Swift GC 1 B (R HUB)
|
Continental C 125/125
|
74B-58
|
Bellanca 14 9 B
|
Rearwin 5 F, 5 G/90
|
74CF-57
|
Bellanca 14 12 F 3
|
Franklin 6 AC 264 F3/120
|
74FC-46
|
Commonwealth Skyranger
|
Continental C 85
|
74FC-49
|
Cessna 120, 140
|
Continental C 85
|
74FC-48
|
80 Canuck
|
Continental C75/75
|
74FCT-48
|
Ercoupe 415 C
|
Continental C 75
|
74FDS-45
|
Monocoupe 90 A F
|
Franklin 4 AC 199 E 3/90
|
74FDS-48
|
Monocoupe 90 A F
|
Franklin 4 AC 199 E 3/90
|
74FE-44
|
Call A
|
Lycoming O 235/100
|
Piper A E 1, J 5 C
|
Lycoming O 235/100
|
|
74FE-46
|
Call A
|
Lycoming O 235/100
|
Piper A E 1, J 5 C
|
Lycoming O 235/100
|
|
74FK-43
|
Fleet 80 Canuck
|
Continental C 85/85
|
74FK-44
|
Cessna 120, 140
|
Continental C 85/85
|
Commonweath
|
Continental C 85/85
|
|
74FK-45
|
Cessna 120, 140
|
Continental C 85/85
|
Ercoupe 415C,415CD,415D
|
Continental C75/75
|
|
Ercoupe 415D,E,G
|
Continental C85/85
|
|
Fairchild PT-19A,B (A HUB)
|
Ranger 6 440 C 2/180
|
|
74FK-46
|
Commonweath
|
Continental C 85/85
|
74FK-47
|
Ercoupe 415C,415CD,415D
|
Continental C75/75
|
Ercoupe 415D,E,G
|
Continental C85/85
|
|
74FK-48
|
80 Canuck
|
Continental C75/75
|
Cessna 140
|
Continental C 90/90
|
|
74FK-49
|
Cessna 120, 140
|
Continental C 85
|
74FKT-48
|
Ercoupe 415 C
|
Continental C 75
|
74FM-44
|
Call Air A
|
Lycoming O 235
|
74FM-46
|
Call Air A
|
Lycoming O 235
|
74FM-47
|
Piper PA-12 (108 HP)
|
Lycoming O 235 C 1/108
|
Piper PA-14, PA-16, PA-18, PA-20
|
Lycoming O 235 C 1/108
|
|
Piper PA-18, PA-18 A
|
Lycoming O 290 D/125
|
|
Piper PA-18, PA-18 A (135 HP)
|
Lycoming O 290 D 2/135
|
|
74FM-49
|
Piper PA-14, PA-16, PA-18, PA-20
|
Lycoming O 235 C 1/108
|
Piper PA-18, PA-18 A
|
Lycoming O 290 D/125
|
|
Piper PA-18, PA-18 A (135 HP)
|
Lycoming O 290 D 2/135
|
|
74FM-54
|
Piper PA-20, PA-22 125
|
Lycoming O 290 D/125
|
Piper PA-20, PA-22 135
|
Lycoming O 290 D 2/135
|
|
74LN-60
|
Bellanca 14 9 L
|
Lenape L M 5
|
74RR-66
|
Bellanca 14 13, 14 13 2
|
Franklin 6A4 150 B3/150
|
Bellanca Cruisair
|
Franklin 6A4 150 B3/150
|
|
755CF-40
|
Funk B
|
Funk E/63
|
76046
|
Luscombe 8A
|
Continental A 65
|
76B-47
|
Piper J 3 C 50
|
Continental A 50/50
|
Piper J 4
|
Continental A 50/50
|
|
Porterfield C P 50, C P 55
|
Continental A 50/50
|
|
76B-49
|
Piper J 3 C 50
|
Continental A 50/50
|
Piper J 4
|
Continental A 50/50
|
|
Porterfield C P 50, C P 55
|
Continental A 50/50
|
|
Taylorcraft BCS
|
Continental A 50
|
|
76B-51
|
Aeronca K C A, 50 C, 50 TC
|
Continental A 50
|
Luscombe 8
|
Continental A 50/50
|
|
Taylorcraft BC
|
Continental A 50/50
|
|
76C-38
|
Aeronca S 65 C, S 65 CA
|
Continental A 65
|
Piper J3C 65S
|
Continental A 65
|
|
Piper J 4 AS
|
Continental A 65
|
|
76C-40
|
Aeronca S 65 C, S 65 CA
|
Continental A 65
|
Piper J3C 65S, J4AS
|
Continental A 65
|
|
Taylorcraft BCS-12D
|
Continental A 65
|
|
76C-42
|
Luscombe 8A Seaplane
|
Continental A 65
|
76C-44
|
Luscombe 8A
|
Continental A 65
|
76CK-34
|
Aeronca S 65 C, S 65 CA
|
Continental A 65/65
|
Aeronca S7AC, S11AC
|
Continental A 65/65
|
|
Piper J 3 C 65 S
|
Continental A 65/65
|
|
Piper PA-11 Seaplane (65 HP)
|
Continental A 65/65
|
|
Taylorcraft BCS-12D, BCS-65
|
Continental A 65/65
|
|
Taylorcraft BCS-1265, BCS-12D1
|
Continental A 65/65
|
|
76CK-36
|
Aeronca S 65 C, S 65 CA
|
Continental A 65/65
|
Aeronca S7AC, S11AC
|
Continental A 65/65
|
|
Piper J 3 C 65 S
|
Continental A 65/65
|
|
Piper PA-11 Seaplane (65 HP)
|
Continental A 65/65
|
|
Taylorcraft BCS-12D, BCS-65
|
Continental A 65/65
|
|
Taylorcraft BCS-1265, BCS-12D1
|
Continental A 65/65
|
|
76CK-38
|
Luscombe 8A Seaplane
|
Continental A 65/65
|
Piper PA-11 Seaplane (90 HP)
|
Continental C 90/90
|
|
76CK-40
|
Luscombe 8A Seaplane
|
Continental A 65/65
|
Taylorcraft CS 12 D
|
Continental A 65/65
|
|
76CK-42
|
Luscombe 8A, Seaplane
|
Continental A 65/65
|
Taylorcraft CS 12 D
|
Continental A 65/65
|
|
Taylorcraft CS65, BCS 12 65
|
Continental A 65/65
|
|
76CK-44
|
Luscombe 8A
|
Continental A 65/65
|
76D-57
|
Monocoupe 90, 90A
|
Lambert R 266/90
|
76JA-53
|
Stinson 108, 150
|
Franklin 6A4 150 B31/150
|
76JB-44
|
Piper L 14
|
Lycoming O 290/125
|
76JB-48
|
Call A2
|
Lycoming O 290/125
|
Call A3
|
Continental C 125/125
|
|
76JR-51
|
Stinson 108, 108-1 Seaplane
|
Franklin 6A4 150 B3/150
|
Stinson 108-2 Seaplane
|
Franklin 6A4 165 B3/165
|
|
76JR-53
|
Stinson 108, 108-1, 150
|
Franklin 6A4 150 B3/150
|
Stinson 108, 108-1 Seaplane
|
Franklin 6A4 150 B3/150
|
|
Stinson 108-2, 108-3
|
Franklin 6A4 165 B3/165
|
|
Stinson 108-2 Seaplane
|
Franklin 6A4 165 B3/165
|
|
76JR-55
|
Stinson 108, 108-1
|
Franklin 6A4 150 B3/150
|
Stinson 108-2, 108-3
|
Franklin 6A4 165 B3/165
|
|
76L-56
|
Funk B 75 L
|
Lycoming GO 145 C/75
|
76L-58
|
Fairchild PT-26
|
Ranger 6 440 C 5/200
|
Funk B75L
|
Lycoming GO 175C/75
|
|
76RK-40
|
Fleet 80 Canuck Seaplane
|
Continental C 85/85
|
76RM-41
|
Piper PA-12 Seaplane
|
Lycoming O 235 C /100
|
76RM-43
|
Piper PA-12, J5C
|
Lycoming O 235 C/100
|
76RM-44
|
Piper PA-12, J5C
|
Lycoming O 235 C/100
|
76RM-46
|
Piper PA-12 (108 HP)
|
Lycoming O 235 C 1/108
|
78HW-63
|
Culver Dart GW
|
Warner Scarab Junior
|
78LY-52
|
Piper J 5 B
|
Lycoming G O 145 C/75
|
Piper L 4G
|
Lycoming GO 145 C3/75
|
|
78R-50
|
Porterfield 35 70
|
Rearwin 5 D E/70
|
Porterfield 90
|
Leblond 5 DF/90
|
|
Rearwin 7000
|
Rearwin 5 D E/70
|
|
Rearwin 7000
|
Leblond 5 D E/70
|
|
Rearwin 8500, 9000 KR, 9000 L
|
Rearwin 5 G/85-90
|
|
78R-52
|
Davis D 1 66
|
Lablond 5 DF, 5 F
|
78R-54
|
Aeronca L B
|
Lablond 5 DF, 5 F
|
Culver Dart GK, G
|
Lablond 5 F
|
|
78R-57
|
Rearwin 8125, 8135, 8135T
|
Rearwin 7 F, 7 G/120
|
78R-59
|
Rearwin 8125, 8135, 8135T
|
Rearwin 7 F, 7 G/120
|
80CL
|
Stearman Hammond Y1
|
Menasco C4S/150
|
80EY-80
|
Luscombe 11A
|
Continental E 165/165
|
80R-70
|
Ryan S T A
|
Menaso C 4/125
|
Rearwin 6000M
|
Menaso C 4/125
|
|
80R-72
|
Ryan STA Special
|
Menasco C4S/150
|
80RA-77
|
Ryan SCW 145
|
Warner Super Scarab/145
|
80W
|
Aeronca L C
|
Warner Scarab Jr./90
|
Porterfield 35 W
|
Warner Scarab Jr./90
|
|
Porterfield 90
|
Warner Scarab Jr./90
|
|
Rearwin 9000
|
Warner Scarab Jr./90
|
|
82R-77
|
Ryan SCW 145
|
Warner Super Scarab/145
|
82R-81
|
Cessna C34, C37, C38, C145
|
Warner Super Scarab/145
|
82RA-77
|
Ryan SCW 145 (A HUB)
|
Warner Super Scarab/145
|
82RA-81
|
Cessna C34, C37, C38, C145 (A HUB)
|
Warner Super Scarab/145
|
Cessna C165
|
Warner Super Scarab/145
|
|
82RS-72
|
Grumman Widgeon G 44, G44 A
|
Ranger 6 440 C 5/200
|
Grumman OA 14
|
Ranger 6 440 C 5/200
|
|
84
|
Arrow Sport
|
Lablond S D
|
Davis V 3, D1
|
Lablond S D
|
|
Monocoupe Monoprep 70, 113
|
Velie M5/65
|
|
84C
|
Fairchild 22 C 7
|
Roche Rover L 267
|
84D
|
Fairchild C7D
|
Wright Gipsy 90
|
84DL
|
D H Moth 60 GM
|
DeHavilland Gypsy
|
84E
|
Fairchild 22 C 7 A, 24 C 8
|
Cirrus Hidrive Mark III/95
|
Roe Avron Avian
|
Cirrus Mark III/85
|
|
84E-51
|
Great Lakes 2TIA, 2TIE
|
Cirrus Upright Mark III/100
|
84EL-51
|
Great Lakes 2TI, 2TIE
|
Cirrus Mark III/85
|
84ES-51
|
Great Lakes 2TIA
|
Cirrus Upright Mark III/100
|
85LY-57
|
Stinson L 5 (Y HUB)
|
Lycoming O 435 1/190
|
85LY-58
|
Stinson L 5 (Y HUB)
|
Lycoming O 435 1/190
|
85LYA-57
|
Stinson L 5 (YA HUB)
|
Lycoming O 435 1/190
|
85RW-57
|
Stinson L 5 (W HUB)
|
Lycoming O 435/190
|
85RB-57
|
Stinson L 5 (B HUB)
|
Lycoming O 435/190
|
86AAS-54
|
Fairchild C61, UC61K
|
Ranger 6 440 C 5 /200
|
86ABS-54
|
Fairchild C61, UC61K
|
Ranger 6 440 C 5 /200
|
86AB-54
|
Fairchild UC-61K (B HUB)
|
Ranger 6 440 C 5 /200
|
Fairchild C 61 (B HUB)
|
Ranger 6 440 C 5 /200
|
|
86B-58
|
Fairchild F 24 K
|
Ranger 165hp
|
Fairchild 24 R 40
|
Ranger 6 410 b3/165
|
|
86BAS-53
|
Fairchild 24C8F,24C8D (A HUB)
|
Ranger 6 390 B,D,D3/145
|
Fairchild 24H40S
|
Ranger 6 410 B 3/175
|
|
86BAS-55
|
Fairchild 24 R 40 (A HUB)
|
Ranger 6 410 B 3/175
|
Fairchild 24K,24R9,24R9S
|
Ranger 6 410 B1,B2/165
|
|
Fairchild 24C8E, 24C8C
|
Warner Super Scarab/145
|
|
86BAS-58
|
Fairchild 24C8F,24H (A HUB)
|
Ranger 6 390 D 3/150
|
Fairchild 24C8E, 24C8C
|
Warner Super Scarab/145
|
|
Fairchild 24K,24R9,24R9S
|
Ranger 6 410 B1,B2/165
|
|
86BB-55
|
Fairchild 24R46 Seaplane
|
Ranger 6 440 C 3/175
|
86BS-53
|
Fairchild 24C8F,24C8D
|
Ranger 6 390 B,D,D3/145
|
Fairchild 24H40S
|
Ranger 6 410 B 3/175
|
|
86BS-55
|
Fairchild 24K,24R9,24R9S
|
Ranger 6 410 B1,B2/165
|
Fairchild 24 R 40
|
Ranger 6 410 B 3/175
|
|
86BS-58
|
Fairchild 24C8F,24H
|
Ranger 6 390 D 3/150
|
Fairchild 24K,24R9,24R9S
|
Ranger 6 410 B1,B2/165
|
|
86C-63
|
Fairchild 24C8E,24C8C
|
Warner Super Scarab/145
|
Fairchild 24 Seaplane
|
Warner Super Scarab/145
|
|
86C-67
|
Fairchild 24J,24G,24W9
|
Warner Super Scarab/145
|
Fairchild 24 W 40,24 W 41
|
Warner Super Scarab/145
|
|
Meyers OTW 145
|
Warner Super Scarab/145
|
|
86C-69
|
Fairchild 22 C 7 G, F
|
Warner Super Scarab/145
|
Luscombe Phantom 1, 1S
|
Warner Super Scarab/145
|
|
86CA-63
|
Fairchild 24C8E,24C8C (A HUB)
|
Warner Super Scarab/145
|
Fairchild 24 Seaplane (A HUB)
|
Warner Super Scarab/145
|
|
86CA-67
|
Fairchild 24J,24G,24W9 (A HUB)
|
Warner Super Scarab/145
|
Fairchild 24 W 40,24 W 41 (A HUB)
|
Warner Super Scarab/145
|
|
Meyers OTW 145
|
Warner Super Scarab/145
|
|
86CA-69
|
Fairchild 22 C 7 G, F
|
Warner Super Scarab/165
|
Fairchild 24J,24G,24W9 (A HUB)
|
Warner Super Scarab/145
|
|
Fairchild 24 W 40,24 W 41 (A HUB)
|
Warner Super Scarab/145
|
|
Fairchild M 62 B (A HUB)
|
Warner Super Scarab 165/165
|
|
Fairchild C 61,24W41A (A HUB)
|
Warner Super Scarab 165/165
|
|
Fairchild UC-61 (A HUB)
|
Warner Super Scarab 165/165
|
|
Luscombe Phantom 1, 1S
|
Warner Super Scarab/145
|
|
86CASP-76
|
Ryan ST3KR, PT-21
|
Kinner B54/132
|
86CB-63
|
Fairchild 24C8E,24C8C (A HUB)
|
Warner Super Scarab/145
|
Fairchild 24 Seaplane (A HUB)
|
Warner Super Scarab/145
|
|
86CB-67
|
Fairchild 24 W 40, 24 W 41
|
Warner Super Scarab/145
|
Fairchild 24J,24G,24W9 (A HUB)
|
Warner Super Scarab/145
|
|
Meyers OTW 145
|
Warner Super Scarab/145
|
|
86CB-69
|
Fairchild 22 C 7 G, F
|
Warner Super Scarab
|
Fairchild M 62 B (B HUB)
|
Warner Super Scarab 165/165
|
|
Fairchild C61, UC-61 (B HUB)
|
Warner Super Scarab 165/165
|
|
Fairchild 24W46,C 61,24W41A (B)
|
Warner Super Scarab 165/165
|
|
Fairchild 24 W 40,24 W 41 (A HUB)
|
Warner Super Scarab/145
|
|
Fairchild 24J,24G,24W9 (A HUB)
|
Warner Super Scarab/145
|
|
Luscombe Phantom 1, 1S
|
Warner Super Scarab/145
|
|
86M-54
|
D H Trainer
|
Menasco D 4
|
86R-58
|
Fairchild M 62A,PT-19
|
Ranger 6 440 C 3/180
|
Fairchild M 62A 3
|
Ranger 6 440 C 5/200
|
|
86R-61
|
Fairchild M 62A,PT-19
|
Ranger 6 440 C 3/180
|
Fairchild M 62A 3
|
Ranger 6 440 C 5/200
|
|
Fairchild PT-19A,B
|
Ranger 6 440 C 2/180
|
|
Fairchild PT-26
|
Ranger 6 440 C 5/200
|
|
Fleet PT-19A
|
Ranger 6 440 C 2/180
|
|
Fleet PT-26
|
Ranger 6 440 C 5/200
|
|
86RA-58
|
Fairchild M 62A,PT-19 (A HUB)
|
Ranger 6 440 C 3/180
|
Fairchild M 62A 3 (A HUB)
|
Ranger 6 440 C 5/200
|
|
86RA-61
|
Fairchild M 62A,PT-19 (A HUB)
|
Ranger 6 440 C 3/180
|
Fairchild M 62A 3 (A HUB)
|
Ranger 6 440 C 5/200
|
|
Fairchild PT-19A,B (A HUB)
|
Ranger 6 440 C 2/180
|
|
Fairchild PT-26 (A HUB)
|
Ranger 6 440 C 5/200
|
|
Fleet PT-19A (A HUB)
|
Ranger 6 440 C 2/180
|
|
Fleet PT-26 (A HUB)
|
Ranger 6 440 C 5/200
|
|
86RA-62
|
Fairchild M 62A,PT-19 (A HUB)
|
Ranger 6 440 C 3/180
|
Fairchild M 62A 3 (A HUB)
|
Ranger 6 440 C 5/200
|
|
Fairchild PT-19A,B (A HUB)
|
Ranger 6 440 C 2/180
|
|
Fairchild PT-26 (A HUB)
|
Ranger 6 440 C 5/200
|
|
Fleet PT-19A (A HUB)
|
Ranger 6 440 C 2/180
|
|
Fleet PT-26 (A HUB)
|
Ranger 6 440 C 5/200
|
|
86RB-60
|
Fairchild 24R46
|
Ranger 6 440 C 3/175
|
86RB-61
|
Fairchild PT-19A,B (B HUB)
|
Ranger 6 440 C 2/180
|
Fairchild PT-26 (B HUB)
|
Ranger 6 440 C 5/200
|
|
Fairchild M62A
|
Ranger 6 440 C 2/180
|
|
Fleet PT-19A (B HUB)
|
Ranger 6 440 C 2/180
|
|
Fleet PT-26 (B HUB)
|
Ranger 6 440 C 5/200
|
|
88A
|
Fairchild 22 C 7 D
|
Wright Gypsy L 320/90
|
Travelair 12Q
|
Wright Gypsy L 320/90
|
|
90AA-64
|
Boeing PT-17, N2S3, A75N1
|
Continental R 670 S
|
90AA-68
|
Boeing PT-13, N2S3
|
Lycoming R 680 11
|
Boeing PT-17, N2S3, A75N1
|
Continental R 670 S
|
|
90AB-64
|
Boeing PT-17, N2S3, A75N1
|
Continental R 670 S
|
90AB-68
|
Boeing PT-17, N2S3, A75N1
|
Continental R 670 S
|
90AC-64
|
Boeing PT-17, N2S3, A75N1
|
Continental R 670 S
|
90AC-68
|
Boeing PT-17, N2S3, A75N1
|
Continental R 670 S
|
90BA-45
|
Bird B W
|
Warner Scarab/125
|
Commandaire 3 C, 3 A
|
Warner Scarab 125
|
|
Davis D 1 W
|
Warner Scarab 125
|
|
Fairchild 22 C 7 E, C5, C6, 24 C8A
|
Warner Scarab 125
|
|
Fleet 1
|
Warner Scarab/125
|
|
Meyers OTW 120
|
Warner Scarab/125
|
|
Waco RNF, RBA
|
Warner Scarab/125
|
|
Howard DGA18
|
Warner Scarab/125
|
|
Travelair W4000, 12W
|
Warner Scarab/125
|
|
90BA-49
|
American Ealge 129, 201
|
Kinner K5/100
|
Arrow Sport
|
Kinner K5/100
|
|
Bird B K
|
Kinner K5/100
|
|
Davis D 1 K
|
Kinner K5/100
|
|
Fairchild KR 21
|
Kinner K 5
|
|
Fleet 2, 91
|
Kinner K 5/100
|
|
Kinner K Sportster
|
Kinner K 5
|
|
Lincoln PTK
|
Kinner K 5
|
|
Travelair K4000
|
Kinner K 5
|
|
90BA-51
|
Cessna AW
|
Warner Scarab 125
|
90BAL-61
|
Arrow F
|
Arrow V 8 F
|
90D-67
|
Bird C K
|
Kinner B 5/125
|
Fairchild KR 21, B
|
Kinner B5
|
|
Fleet 7,8,9,10,16B
|
Kinner B 5/125
|
|
Travelair 16K
|
Kinner B 5/125
|
|
Waco INF, IBA
|
Kinner B 5/125
|
|
90DA-67
|
Fleet 7,8,9,10,16B (A HUB)
|
Kinner B 5/125
|
90H-84
|
Ryan PT 22
|
Kinner R 56/160
|
Ryan S T 3 K R
|
Kinner R 56/160
|
|
90H-86
|
Ryan ST3KR, PT-22
|
Kinner R 56/160
|
Ryan S T 3 K R
|
Kinner R 56/160
|
|
90HA-84
|
Ryan PT 22 (A HUB)
|
Kinner R 56/160
|
90HA-86
|
Ryan ST3KR, PT 22 (A HUB)
|
Kinner R 56/160
|
Ryan S T 3 K R (A HUB)
|
Kinner R 56/160
|
|
90HB-84
|
Ryan PT 22 (B HUB)
|
Kinner R 56/160
|
90HB-86
|
Ryan ST3KR, PT 22 (B HUB)
|
Kinner R 56/160
|
90HASP-86
|
Ryan ST3KR, PT-22
|
Kinner R 56/160
|
90JA-79
|
Cessna T50, AT17
|
Jacobs L 4 MB/225
|
Cessna UC-78
|
Jacobs L 4 MB/225
|
|
90JA-81
|
Cessna T50, AT17
|
Jacobs L 4 MB/225-245
|
Cessna UC-78
|
Jacobs L 4 MB/225
|
|
90LA-76
|
Boeing PT-17
|
Continental R 670 5/220
|
90LA-78
|
Aeronca PT-23
|
Continental R 670 5/220
|
Fairchild PT-23,M 62 C
|
Continental W670/220
|
|
Fleet PT-23
|
Continental R 670 5/220
|
|
Fleet PT-23
|
Continental R 670 5/220
|
|
Howard PT-23
|
Continental R 670 5/220
|
|
St. Louis PT-23
|
Continental R 670 5/220
|
|
90T6JA-72
|
Great Lakes R755 (A HUB)
|
Jacobs R-755B2M/225,245,275
|
Waco YMF5 (A HUB)
|
Jacobs R-755B2M/225,245,275
|
|
90T6JB-72
|
Great Lakes R755 (B HUB)
|
Jacobs R-755B2M/225,245,275
|
Waco YMF5 (B HUB)
|
Jacobs R-755B2M/225,245,275
|
|
92H-72
|
Fairchild 24
|
Kinner R 56/160
|
Howard DGA18K
|
Kinner R 56/160
|
|
92H-76
|
Meyers OTW 160
|
Kinner R 56/160
|
92HBSPA-74
|
Howard DGA18K
|
Kinner R 52/160
|
94A-60
|
Waco UBF, UMF
|
Continental R 670 A/210
|
96B
|
Bird C I
|
Jacobs L A 1
|
Waco PBA, PFF, PCF, PLA
|
Jacobs L A 1
|
|
96JA-4-68
|
Great Lakes R755 (A HUB)
|
Jacobs R-755B2M/225,245,275
|
Waco YMF5 (A HUB)
|
Jacobs R-755B2M/225,245,275
|
|
Waco YMF5FC (A HUB)
|
Jacobs R-755B2M/225,245,275
|
|
96JB-4-68
|
Great Lakes R755 (B HUB)
|
Jacobs R-755B2M/225,245,275
|
Waco YMF5 (B HUB)
|
Jacobs R-755B2M/225,245,275
|
|
Waco YMF5FC (B HUB)
|
Jacobs R-755B2M/225,245,275
|
|
96T-69
|
Commandaire 3 C, 3 B
|
Siemens SH 14
|
Curtiss Wright Robin
|
Tank V 502, V 470
|
|
Travelair T2000
|
Tank V502/115
|
|
Waco GXE
|
Tank V502/115
|
|
98AA-64
|
Boeing PT 13 B, D, N 2 S-5
|
Lycoming R 680 11/220
|
Boeing PT 17, A, N 2 S-3
|
Continental R 670 5/220
|
|
Boeing PT 13, N2S375 Series
|
Lycoming R 680 11/220-225
|
|
Boeing PT 17, N3S375 Series
|
Continental R 670 5/220
|
|
98AA-66
|
Boeing PT 13 B, D, N 2 S-5
|
Lycoming R 680 11/220
|
Boeing PT 17, A, N 2 S-3
|
Continental R 670 5/220
|
|
Boeing PT 13, N2S375 Series
|
Lycoming R 680 11/220-225
|
|
Boeing PT 17, N3S375 Series
|
Continental R 670 5/220
|
|
98AA-68
|
Boeing PT 13, N2S375 Series
|
Lycoming R 680 11/220-225
|
Boeing PT 17, N3S375 Series
|
Continental R 670 5/220
|
|
Waco YPF7
|
Continental W6706A/220
|
|
98AB-64
|
Boeing PT 17, N2S375 Series (B HUB)
|
Continental R 670 5/220
|
98AB-66
|
Boeing PT 17, N2S375 Series (B HUB)
|
Continental R 670 5/220
|
98AB-68
|
Boeing PT 17, N2S375 Series (B HUB)
|
Continental R 670 5/220
|
98AC-64
|
Boeing PT 17, N2S375 Series (C HUB)
|
Continental R 670 5/220
|
98AC-66
|
Boeing PT 17, N2S375 Series (C HUB)
|
Continental R 670 5/220
|
98AC-68
|
Boeing PT 17, N2S375 Series (C HUB)
|
Continental R 670 5/220
|
Waco YPT-14, UPF-7, UIC
|
Continental W 670 BA/225
|
|
98C-70
|
Waco YPT-14, UPF-7, UIC
|
Continental W 670 BA/225
|
100CC-58
|
Waco QCF, QDC, QSO
|
Continental A70, A70 2/165
|
100CC-65
|
Waco UKC, UIC, UBA, UEC
|
Continental R 670 A/210
|
100CD-67
|
Waco YMF, YQC, YOC, YKS, YKC
|
Jacobs L4/225
|
102
|
OX-5 All makes and models
|
|
102A
|
Waco GXE
|
Curtiss OXX-6
|
707-80
|
Cessna UC-78
|
Jacobs L4M B/225
|
755
|
American Eaglet B 31
|
Szekely SR3
|
Buhl LA I
|
Szekely SR3
|
|
Rearwin 3000
|
Szekely SR3
|
|
755-A
|
Piper F2
|
Lenape AR3/50
|
755A-1
|
American Eaglet B31
|
Szekely SR3
|
American Eaglet 231
|
Salmson AD 9
|
|
755-C
|
Rearwin 4000
|
Lenape AR3/50
|
755CF
|
Funk B
|
Funk E/63
|
755L
|
Curtiss Wright C W L Jr.
|
Szekely SR3
|
A-1
|
American Eaglet 231
|
Sammson AD 9 40 hp
|
Copyright, 2012
